Solid Wood Shutter Parts for Purchase
- How to Purchase the correct Plantation Shutter Parts !
1. Measure your windows or openings (See Measurements Page for further information).
2. Decide which hanging scenario is right for your windows or openings. Below you will see a few hanging styles. Shutter panels can be hung above another to achieve a larger opening or to hang different style of panels as seen below.
3. Note that our shutter parts are separated into five shutter heights and eight shutter widths. The sizes are standardized so that any window opening can be covered with one or more shutter panels. A shutter panel when fully assembled can be cut up to 7/16" on each side (total of 7/8" in width) and 1" off the top and 1" off the bottom if required to fit into an area. Fitting to a width is suggested to undersize the shutter panel width and add hanging strips cut to a particular width to achieve a proper fit. See the images above for clearances using a non-mortise hinge.
Shutter Panel Sizes available for individual Purchase Parts are as follows:
Widths=> 10"- 12"- 14"- 16"- 18"- 20"- 22"- 24"
Lengths=> 24" 36" 48" 60" 72"
24" Tall require 6 louvers
36" Tall require 11 louvers
48" Tall require 16 louvers
60" Tall require 20 louvers
72" Tall require 25 louvers
The Following parts are for one shutter panel.
Please be aware that shipping costs are NOT included. Contact us for shipping costs by hitting the Contact Us button and give us your zip code, sizes and quantities of requested shutters. Also, if picking up or having products shipped to a Pennsylvania address, a 6% Sales Tax should be included.
Widths=> 10"- 12"- 14"- 16"- 18"- 20"- 22"- 24"
Lengths=> 24" 36" 48" 60" 72"
24" Tall require 6 louvers
36" Tall require 11 louvers
48" Tall require 16 louvers
60" Tall require 20 louvers
72" Tall require 25 louvers
The Following parts are for one shutter panel.
Please be aware that shipping costs are NOT included. Contact us for shipping costs by hitting the Contact Us button and give us your zip code, sizes and quantities of requested shutters. Also, if picking up or having products shipped to a Pennsylvania address, a 6% Sales Tax should be included.
24" Poplar Stiles (Pr.) - 2-7/8" Louver spacing
One pair of 1" deep x 2" wide X Length Shown, Poplar Vertical frame part with louver pin holes and lower rail assembly holes.
$
10.42
36" Poplar Stiles (Pr.) - 2-7/8" Louver spacing
One pair of 1" deep x 2" wide X Length Shown, Poplar Vertical frame part with louver pin holes and lower rail assembly holes.
$
15.62
48" Poplar Stiles (Pr.) - 2-7/8" Louver spacing
One pair of 1" deep x 2" wide X Length Shown, Poplar Vertical frame part with louver pin holes and lower rail assembly holes.
$
20.83
60" Poplar Stiles (Pr.) - 20-7/8" Louver spacing
One pair of 1" deep x 2" wide X Length Shown, Poplar Vertical frame part with louver pin holes and lower rail assembly holes.
$
26.04
72" Poplar Stiles (Pr.) - 2-7/8" Louver spacing
One pair of 1" deep x 2" wide X Length Shown, Poplar Vertical frame part with louver pin holes and lower rail assembly holes.
$
31.25
*******************************************************
10" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
9.45
12" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
10.20
14" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
10.95
16" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
11.70
18" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
12.45
20" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
13.20
22" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
13.95
24" Poplar Upper and Lower Rail Set
One pair of 7/8" deep x 4-1/2" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a shutter panel at the width shown.
$
14.70
*******************************************************
Mid Rail - Used in our SHS-1 style shutters to split the top and bottom louver sets in tall shutter panels (see detail above) The mid rail takes the place of one horizontal louver space.
10" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
4.48
Poplar Mid Rail
3.25" x 3/4" x length Solid Poplar Mid Rail stock
$
4.90
14" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
5.32
16"Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
5.73
18" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
6.15
20" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
6.57
22" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
6.97
24" Poplar Mid Rail
One 7/8" deep x 3-1/2"" wide X Length Shown, Poplar Horizontal frame part with final machining to assemble and create a SHS-1 style shutter panel at the width shown.
$
7.30
*******************************************************
Louver Packs required for the following shutter heights (each pack contains 9 louvers):
24" Tall require 1 pack
36" & 48" Tall require 2 packs
60" & 72" Tall require 3 packs
24" Tall require 1 pack
36" & 48" Tall require 2 packs
60" & 72" Tall require 3 packs
10" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 10" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
13.25
10" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 10" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
12.35
12" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 12" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
15.29
12" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 12" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
14.45
14" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 14" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
17.84
14" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 14" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
16.85
16" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 16" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
20.39
16" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 16" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
19.26
18" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 18" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
22.93
18" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 18" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
21.67
20" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 20" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
25.48
20" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 20" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
24.08
22" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 22" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
28.03
22" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 22" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
26.48
24" Poplar Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 24" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
30.58
24" Meranti Louver Package -Nine louvers (9) per Package
Nine 2-7/8" wide x length to properly fit a 24" wide shutter panel. Holes drilled for the nylon louver pin and the hidden tilt bar drive pin. Final sanding required.
$
28.89
*******************************************************
Hardware Construction Package
One Package contains:
One Pair of 3" Non-mortise Hinges
8 Eight 2-1/2" Construction Screws
8 Eight 3/8" Wooden Plugs
26 Twenty Six Nylon Louver Pins
13 Thirteen S. S. Hidden Tilt Bar Drive Pins
One Package contains:
One Pair of 3" Non-mortise Hinges
8 Eight 2-1/2" Construction Screws
8 Eight 3/8" Wooden Plugs
26 Twenty Six Nylon Louver Pins
13 Thirteen S. S. Hidden Tilt Bar Drive Pins
Poplar Shutter Hardware Package ( 18" to 36" tall )
24" & 36" Tall shutters require one package, 48", 60" & 72" Tall require two packages.
Included:
24 Nylon Louver Tilt Pins
8- 3" Ring Head Construction Screws
8- 3/8" flat top wood plugs
$
7.50
*******************************************************
Hidden Tilt Bar
The tilt bars are being sold in approx. 48" lengths and each tilt bar will individually accommodate 19 louvers. One tilt bar will handle up to a 58" tall shutter panel. Taller than that will require another tilt bar.
The tilt bars are being sold in approx. 48" lengths and each tilt bar will individually accommodate 19 louvers. One tilt bar will handle up to a 58" tall shutter panel. Taller than that will require another tilt bar.
48" Tilt Bar & Drive pins
Will control up to 19 louvers @64mm (2 7/8" Louver width)
Includes 19 #4 S.S. Drive Pin to attach Tilt Bar to Louvers
Includes 19 #4 S.S. Drive Pin to attach Tilt Bar to Louvers
$
13.75
